ABB Formula MCCB 40 A, 4 Pole, 10 kA, Fixed O/L & Fixed S/C Settings, TMF, A1A 125 TMF 40-400 4p F F
The ABB 1SDA066535R1 is a 4-pole, 125A Molded Case Circuit Breaker (MCCB) from the SACE Formula A1A 125 series. Engineered for tamper-proof protection of 3-phase circuits with a neutral line, it features a fixed thermomagnetic release (TMF) with a preset 125A thermal overload and 1250A instantaneous short-circuit trip threshold.
Product Specification:
- Number of Poles: 4 Poles
- Rated Current / Frame Size: 125 A / 125 A Frame
- Breaking Capacity : 10 kA at 380/415V AC
- Rated Operational Voltage: 550V AC / 250V DC
- Protection Release: Non-adjustable Thermomagnetic (TMF 125-1250)
- Terminal Type: Fixed Front Terminals (F F)
- Dimensions: 130 mm (H) x 101.6 mm (W) x 60 mm (D)
