MCCB-Schneider Electric Easypact CVS 250 Amp 4 Pole FTFM LV525313
The Schneider Electric LV525313 is a 4-pole, 250A Molded Case Circuit Breaker (MCCB) from the EasyPact CVS250B series. Engineered for low-voltage power distribution in commercial buildings and industrial networks, it features a thermal-magnetic trip unit (TM-D) configured with 3 protected poles (4P 3d), a left-side neutral, and an adjustable thermal overload threshold (175–250A).
Product Specification:
- Number of Poles / Configuration: 4 Poles / 3 Poles Protected (4P 3d, Left Neutral)
- Rated Current : 250 A at 40 °C
- Breaking Capacity : 25 kA at 380/415V AC
- Rated Operational Voltage : 440V AC
- Protection Release: Thermal-Magnetic (TM-D) with adjustable thermal overload (0.7–1 × \(I_{n}\)) and a fixed 2500A magnetic trip
- Mounting Type: Fixed type, backplate mounting
- Dimensions: 161 mm (H) x 140 mm (W) x 86 mm (D)
